Product Details:
Payment & Shipping Terms:
|
| Machine Name: | Spiral Duct Forming Machine | Condition: | New |
|---|---|---|---|
| Mainbody: | Sheet & Tube Metal Welded Structure | Applicable Industries: | Food & Beverage Factory, Hotels, Building Material Shops, Construct |
| Control Mode: | CNC Touch Diaplay, PLC Control | Operation: | Automatic,Electric |
| Producing Materials: | Galvanized Sheet Metal, Stainless Steel Plate, Aluminum Sheet | Industry: | Construction Engineering, Air Conditioning, Ventilation Duct |
| Core Components: | PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear | Strip Width: | 134-140 Mm |
| Production Capacity:: | 38m/min | Max Width: | 100-1600 Mm |
| Sheet Thickness: | 0.4-1.2 Mm | Dimension(L*W*H): | 3400*2150*1600mm |
| Weight: | 3200kg | Voltage: | 220V/380V/415V/440V, 50HZ/60HZ, Customized |
| Color: | Gray Black+yellow, Blue+white, Or Customized | After-sales Service Provided:: | Engineers Available To Service Machinery Overseas; Technology Support Online Because Of Covid-19 |
| High Light: | Galvanized Spiral Duct Forming machine,spiral duct making machine,rectangular duct forming machine |
||
Square Air Duct Manufacturing Auto line-III Galvanized sheet flexible Duct making machine
Product Description,
1, Patented mold, easy to adjust, and has its own patent, replace the mold more trouble and save the province of materials
2, High-speed synchronous cutting system
3, PLC control
4, Can be on-site construction
5, Can be adjusted
6, High-quality products, high-quality services
7, The system can handle galvanized sheet, aluminum
8, Automatic roll out of equipment
9, Can produce a variety of different diameter spiral tube
Main Technical Parameters,
| Type | PSL-1600 | |
| Diameter range | Φ80-φ1600mm | |
| Tube length | 125-6000mm | |
| Strip width | 137-140mm | |
| Lock seam | Outside tube,on the inside on request | |
|
Material |
Galvanization | 0.4-1.2mm |
| Stainless steel | 0.4-0.8mm | |
| Aluminum | 0.4-1.2mm | |
| Strip speed | Max:38m/min | |
| Dimensions | 2650x1550x2000mm | |
| Weight | 2200kg | |
| Control system | PLC automatic control | |
| Main motor power | 5.5KW | |
| The power of cutting motor | 4KW | |
| Electrical | 380V/50Hz/3PH Customizable voltage | |
| Working pressure |
0.5-0.7Mpa |
|
