| Product Name: | Automatic Polyurethane Seal Strip Foaming Machine | Product Type: | KW-520C |
|---|---|---|---|
| Industry Applicaiton: | Electrical Cabinet Doors, Panels, Electronics, Filters, Automobiles | Processing Type: | PU Foaming Gasket Machine |
| Application Area: | Manufacturing Plant, Machinery Repair Shops, Sheet Metal Processin | Raw Material:: | Polyurethane Adhesive Glue A+B |
| Mixing Ratio（A:B）: | 1:1 - 1:10 | Repeated Position: | ±0.05mm |
| Control Mode: | CNC System, PLC Control | Automatic: | Fully Automatic |
| CNC System: | Touch Screen WIN 10, | Materials: | Sheet Metal, Plates, Plastic Board, |
| Core Components: | Servo Motors, Pumps,Mixing Head | Producing Size: | 2200x1200x200mm |
| Strip Width: | 5-30mm | Power (kW): | 5.5kw |
| Air Pressure: | 0.6-0.8MPa | Dimension(L*W*H): | 410*330*230CM |
| Voltage: | 220V/380V/415V,50HZ/60HZ 3Ph | Weight: | 2000kg |
| Place Of Origin: | China | Warranty: | 1 Year |
| After-sales Service: | Engineers Available To Service Machine Overseas, Video Technical Support, Media Technical Support Online | ||
| Highlight: | Polyurethane strip Foam Sealing Machine,Foam Sealing Machine Automatic,gasket Glue Dispensing Machine |
||
Polyurethane seal strip foaming machine Automatic PU foam sealing strip gasket Glue Dispensing Machine
Description of machine:
This machine can mix two kinds of raw material (Glue A, B) together and pour to pre-set position, groove, mould, or the flat surface of workpiece directly.
Through chemical reaction, the liquid Glues form elastic sealing strip in seconds.
There is no joint or cut point, so comparing with other kind of sealing its effect is much better and with longer using life. And, during the forming process, the sealing strip surface become very smooth and without any crack, so its sealing effect is perfect. And, because it can stick on the workpiece naturally and tightly, no gluing worker is needed, huge cost is saved from labor and time, etc.
Foam sealing equipment is used more and more in sealing fields like controlling cabinets, lighting, motor vehicle, machining industry, etc. It is leak proof, oil proof, water proof, damping, noise proof, and sealing, etc.
The equipment is driven by servo motors, and the operation is smooth.
The 2D and 3D workpieces can be processed.
The CNC multi-dimensional compensation can realize any track gluing.
The high-precision mixing head with independent intellectual property rights has the excellent performance of instantaneous blocking, drip prevention, turbo charging, 360-degree cleaning and no dead angle.
Stainless steel 316 double pressure tanks equipped with automatic air replenishment and intelligent constant temperature device protects the raw materials (Glue A & B) from normal use even under low temperature environment.
Hand-held operation panel is provided for easy and convenient use.
Foaming Machine Main Parts:
1. Mixing Head:
Water Rinsing & Modular Design, or recycled chemical solvents for arid zone countries.
2- component mixing head with high-pressure water rinsing system and dynamic mixing system, for use with liquid to high-viscous polymer reaction materials for gasketing, gluing and potting.
2. Operation System:
Self-developed CNC System, Multi-language selection, Storing huge frequently-used information, Plus USB interface and G-code program, Manual operation is for choice also, Can be operated simply.
3. Raw Material Banks:
Double walled stainless steel, control temperature automatically.
4. Work table:
Aluminum alloy, strong and durable,
With water and air-cleaning stainless box.
5. Metering System:
Barmag metering pump, Panasonic/Fuji servo motor, Microscale (2-8mm) gluing is workable.
6. Handle Controller:
Easily control, response quick and steady.
7. Driving system:
Panasonic/Fuji servo motors, work steady, long using life.
Main parameters:
| Items | Parameters | |
| Machine | Model | KW-520C |
| Overall space | 4100X3300X2400mm (L*W*H) | |
| Working effective stroke | 2200X1200X200mm (X*Y*Z) | |
| Weight | 2000 KGS | |
| Chemical material | Name | Polyurethane |
| Components | 2 Components ( Glue A+B) | |
| System/operation | Operating system | PC, Win 10 |
| Operating method | Keyboard + Buttons | |
| Mixing head | Model | KW700/KW900 |
| Gasket width | 5-30mm | |
| Clean method | High pressure water clean+ air-blow cleaning | |
| Mixing ratio(A:B) | 1∶1-10∶1 | |
| Output | 1-4 g/s | |
| Repeated position precision | ±0.05mm | |
| Air pressure | 6-8 bar | |
| Mechanical frame | Type | 3-axes linear mechanical arm |
| Speed | 0-250mm/s | |
| Storage tank | Type | Air pressure tank |
| Volume |
A Tank-40L B Tank-40L |
|
| Automatic stirring | A Tank: YES B Tank: NO | |
| Glue refill | Manual (Option: Automatic) | |
| Air refill | Automatic | |
| Working table | Material | Aluminum alloy frame |
| Size | 2000X1000X900mm (L*W*H) | |
| Electric power | Voltage | 380V,50HZ, 3Ph |
| Total Power | 5.5kw | |
